Product Overview
The UNHCR Standard Family Tent is a humanitarian emergency shelter designed for refugee relief operations and disaster response programs. Developed in accordance with widely adopted humanitarian shelter specifications, this tent provides safe, durable, and weather-resistant accommodation for displaced families.
With a main living area of 16 m² and two vestibule spaces, the tent offers practical interior space for sleeping, storage, and daily activities. The structure features high-density polyethylene (HDPE) woven fabric laminated with LDPE coating, providing excellent resistance to rain, UV exposure, and wear in harsh field environments.
The tent is designed to support forcibly displaced populations, including families with children, elderly individuals, pregnant women, and persons with disabilities, ensuring reliable protection in emergency and long-term displacement settings.
Its robust steel frame, reinforced guying system, and modular components allow for rapid deployment, easy transportation, and dependable performance in humanitarian missions worldwide.
Specifications
| Item | Description |
|---|---|
| Product Type | UNHCR Standard Family Tent |
| Main Floor Area | 16 m² |
| Vestibule Area | 3.5 m² × 2 |
| Centre Height | 2.2 m |
| Width | 4 m |
| Ridge Length | 4 m |
| Side Wall Height | 1.25 – 1.40 m |
| Centre Base Length | 6.6 m |
| Inner Tent Centre Height | 2.1 m |
| Inner Tent Width | 3.8 m |
| Inner Tent Wall Height | 1.15 – 1.30 m |
| Inner Tent Base Length | 3.95 m |
| Outer Fabric | Woven HDPE black fibres laminated with white LDPE coating |
| Mosquito Netting | Polyester / Polyethylene |
| Frame | Galvanized or painted steel poles |
| Protection | UV resistant, flame resistant, water resistant |
| Accessories | Guy ropes, pegs, hammer, repair kit |
Key Features
Humanitarian-Grade Shelter Design
Designed for refugee camps and emergency response operations, meeting the functional requirements of humanitarian organizations.
Durable HDPE Laminated Fabric
High-density polyethylene woven fabric with double-sided LDPE lamination provides strong water resistance, durability, and weather protection.
Spacious Family Accommodation
The 16 m² living area with two vestibules allows families to sleep comfortably while providing extra space for storage and daily activities.
Ventilation & Mosquito Protection
Integrated mosquito netting and ventilation openings improve airflow while protecting occupants from insects and tropical environments.
Strong Structural Stability
Equipped with galvanized steel poles, reinforced guy ropes, and ground pegs, ensuring stability under wind and challenging weather conditions.
Rapid Deployment for Emergency Response
The modular structure allows fast installation and easy transportation, making it suitable for disaster relief operations.
Ideal For | Applications
-
Refugee camps
-
Disaster relief operations
-
Humanitarian aid missions
-
Emergency housing for displaced populations
-
NGO and UN emergency shelter programs
-
Temporary shelter during crisis response
Customization Options
As an experienced OEM humanitarian tent manufacturer, Nastocamp offers customization options to meet project requirements:
-
Tent size and layout adjustments
-
Fabric weight and coating specifications
-
Flame-retardant certification options
-
Logo printing for organizations or aid programs
-
Color customization
-
Packaging solutions for bulk humanitarian shipments
-
Customized accessories and spare parts kits
